- Asphalt Heating Drum
- Construction – 3/16” steel: 450 Brinell hardened
- Agitation Paddles – (7) 3/16”: 450 Brinell Hardened
- Rotation – Hydraulically controlled, approx. 9 RPM
- Hydraulics
- Reservoir – 30 Gallon
- Pump – 9.5 gal./minute
- Motor – 38 cubic inch
- Heating System
- Fuel – No. 1 or 2 Diesel, B-5 bio-diesel, or kerosene
- Fuel Storage -80-gallon fuel tank with filter and manual shut-off
- Burner type – Beckett Model SDC
- BTU Output – 700,000
- Engine – 21 BHP Kubota
- Loading/Unloading
- Loading – Milled asphalt or broken chunk pieces up to 12”
- Unloading – Unload directly into application area or into front end loader bucket
